Wacker Neuson BS User Manual

12 Technical data
28 100_0201_td_0001.fm
12 Technical data
12.1 Noise and vibration information
The noise and vibration information listed was determined according to the following guidelines with the
machine-typical operating states / specific test conditions while applying harmonized standards:
 Machines directive 2006/42/EC
 Noise emissions directive 2000/14/EC
In operational application, deviating values may result depending on the prevailing operating conditions.
12.1.1 Noise information
Sound pressure level at the operator's location
 The LWA was determined pursuant to EN ISO 11201 and EN 500-4.
Guaranteed sound power level
 The LWA was determined pursuant to EN ISO 3744 and EN 500-4.
12.1.2 Hand-arm vibration (HAV) information
Weighted total vibration value
 The HAV was determined pursuant to EN ISO 20643 and EN 500-4.
12.2 BS
Designation Unit BS30
Item number 5000005216
Percussion rate rpm
810
Power transmission Centrifugal clutch
Length mm 620
Width mm
363
Height mm 980
Length (ramming shoe) mm
296
Width (ramming shoe) mm 150
Travel speed m/min 19
Weight kg
30.0
Electrical load rating kW 1.5
Nominal speed rpm 4,400
Standard ISO 3046-1
Special lubricant S3 V220C 2
Storage temperature range °C -30 – +50
Operating temperature range °C -10 – +40
Sound pressure level L
pA
dB(A) 98
Sound power level L
WA
measured
guaranteed
dB(A)
dB(A)
105
108
Vibration total value a
hv
m/s
2
12.0
Uncertainty of measurement of
the vibration total value a
hv
m/s
2
3.0
