Rammer
Operation
4.6 Position of the Operator
For optimal control, performance, and minimal hand/arm vibration, follow the
guidelines below when using the machine.
Grasp the handle with both hands as shown.
Stand behind the rammer, walking slowly and guiding the direction of travel as the
machine moves forward.
Note: Hand/Arm Vibration (HAV) has been optimized for the hand position shown.
Reported HAV levels are measured at position A in conformance with EN 1033 and
ISO 5349 standards.
4.7 Before Starting
1. Read safety instructions at the beginning of this manual.
2. Make sure that the fuel tank is full.
3. On machines with oil tanks:
► Make sure the oil tank is at least ¼ full.
► Check the oil lines for air.
4. Check the fuel lines and fittings.
5. Check the air filter.
6. Check the ramming system oil level.
7. Place the rammer on loose soil or gravel. DO NOT start the rammer on hard
surfaces such as asphalt or concrete.
