BA D18 us* 1.1 * D18w710.fm 7-35
Maintenance 7
Adding hydraulic oil
The filler opening of the hydraulic oil reservoir is located behind the
maintenance flap on the left.
1. Stop and park the machine. Stop the engine – see “Preparing
lubrication” on page 7-8.
2. Release the pressure in the hydraulic system.
3. Open the maintenance flap on the left.
4. Clean the area around the filler opening of the hydraulic oil with a lint-
free cloth.
5. Open cover A of the filler opening for the hydraulic oil slowly to release
the pressure inside the hydraulic oil reservoir.
6. Add hydraulic oil until the oil level is approximately in the middle of the
sight glass.
7. Put cover A into place and screw it on tightly.
8. Close and lock the maintenance flap on the left.
Use a suitable container to collect fluids and lubricants as they flow out
and dispose of them in an environmentally friendly manner.
