BA D18 us* 1.1 * D18i400.fm
4-19
Putting into operation
4
Designation
See page
1
Operator seat and seat belt
4-4
;
4-6
2
Service brake
5-4
3
Steering-column lever (
option for Austrian roa
d
traffic regulations StVZO)
4-22
4
Display element
4-24
5
Switch panel
4-22
6
Accelerator pedal
5-3
7
12 V connection
4-17
8
Docume
nt box
4-17
9
Control lever
5-3
10
Operating hydr
aulics lock lever
5-10
11
Parking brake
5-4
78
80
Table of Contents
Default Chapter
3
Table of Contents
3
1 Foreword
11
Operator's Manual
11
Warranty and Liability
17
2 Safety
19
Safety Symbols and Signal Words
19
Safety 2.1 Safety Symbols and Signal Words
19
Qualification of Operating Personnel
20
Conduct
21
Operation
22
Machine Operation
24
Lifting Gear Applications
26
Trailer Operation
28
Attachment Operation
28
Towing, Loading and Transporting
29
Maintenance
31
Measures for Avoiding Risks
35
3 Introduction
39
Machine Overview
39
Introduction 3.1 Machine Overview
39
Brief Description of Machine
41
Information and Regulations on Use
42
Labels
43
4 Putting into Operation
61
Cabin/Control Stand
61
Emergency Exit
63
Operator Seat
65
Overview of Control Elements
77
Indicator Lights and Warning Lights (Overview)
84
Preparatory Work
89
Starting and Stopping the Engine
94
Starting the Engine
95
Stopping the Engine
100
5 Operation
101
Steering System
102
Operation 5.1 Steering System
102
Accelerator Actuation
103
Brakes
104
Machine Travel
109
Differential Lock
115
Lights/Signaling System
116
Wiper/Wash System (Option)
120
Heating, Ventilation and Air Conditioning System
121
Operating Hydraulics
122
Attachments
124
Work Operation
124
Emergency Lowering
129
Options
129
Putting out of Operation/Back into Operation
132
Permanently Putting out of Operation
134
6 Transportation
135
Towing the Machine
135
Transportation 6.1 Towing the Machine
135
Loading the Machine
139
Transporting the Machine
143
7 Maintenance
145
Information on Maintenance
145
Maintenance Overview
146
Fluids and Lubricants
154
Maintenance Accesses
157
Cleaning and Maintenance
160
Seat Belt
162
Lubrication Work
163
Fuel System
163
Engine Lubrication System
169
Cooling System
172
Air Filter
176
V-Belt
177
Hydraulic System
177
Electrical System
181
Heating, Ventilation and Air Conditioning System
183
Washer System
183
Axles
183
Braking System
183
Tires
184
Maintenance of Attachments
185
Maintenance of Options
185
Exhaust Gas Treatment
186
Machine Preservation
192
8 Malfunctions
193
Engine Warning Lights
193
Malfunctions 8.1 Engine Warning Lights
193
Engine and Engine Oil Indicator Lights
194
Malfunctions (Display Element/Multifunctional Display)
194
General Malfunctions
196
9 Technical Data
201
Model Designations and Trade Names
201
Engine
201
Traveling Drive/Axles
202
Brakes
203
Tires
204
Steering System
204
Operating Hydraulics
204
Electrical System
205
Tightening Torques
209
Coolant
210
Noise Emissions
210
Vibration
211
Weight
214
Payload
215
Dimensions
216
