EHB 11 Operation
31
7.3 Changing tools
7.3.1 General instructions
General notes
Tools are easily changed with all tool holders without requiring additional tools.
Only use tools with intact shanks.
Before inserting the tool, ensure that the tool is sufficiently sharpened and that it
is suitable for the intended application.
7.3.2 Tool holder SDS-max
Inserting tool
1. Clean tool end.
2. Insert tool into tool holder.
3. Turn tool and press into holder until automatically locked into place.
4. Check to see if the tool is locked by pulling on the tool.
Item Designation
1Tool
2 Tool holder
