Operation EHB 11
7.2.4 Adjustable depth gauge
Adjusting the depth gauge
1. Loosen the wing bolt.
2. Adjust depth gauge as needed by pulling out or pushing in.
3. Retighten the wing bolt firmly.
Item Designation
1 Wing bolt
2 Adjustable depth gauge
