7 Maintenance
6. Install the lifting gear at the points on the cabin provided for lifting the
machine. The required length L1 is 1000 mm (39.4 in).
7. Apply tension to the cabin with the lifting gear.
8. Canopy: Remove the electric connector B. The connector is located
on the left behind the operator seat.
Install the protective cap to protect the connector.
9. Cabin (option): Fold cover C forward. Remove the electric connector
B. The connector is located on the left behind the operator seat.
Install the protective cap to protect the connector.
10.Raise the floor mat on either side.
11.Remove screws D on either side in the leg-room area.
Fig. 244Installing lifting gear
L1
L1
L1
Fig. 245Removing the connector (canopy)
B
Fig. 246Removing the connector (cabin)
B
C
Fig. 247Screws on the left and right
D
