Wacker Neuson GP 3800A

Operation GP 3800A
24 wc_tx000785gb.fm
3.5.14 Insert the nuts (n) onto the screws and tighten. Torque to 7.5 Nm (5.25
ft.lbs.).
3.5.15 Align the holes found in the handles (a, j) to the holes of the brackets
(1) on the frame.
3.5.16 Insert M6 x 16 screws (l) through the handles, then through the
brackets on the frame.
3.5.17 Insert nuts (m) onto the screws and tighten. Torque to 7.5 Nm (5.25
ft.lbs.).
