Technical Data VPR 1330
wc_td000014gb.fm 14
3. Technical Data
3.1 Engine Data
VPR 1330
0006512
Rev. 102 and lower
VPR 1330
0006512
Rev. 103 and higher
Engine
Engine Make
Robin
Engine Model
EY15 (W1-145) EH122 (YD 4020)
Rated Power
kW (Hp) 2.6 (3.5) 2.9 (4.0)
Engine Speed - full load
rpm 3500 ± 100
Engine Speed - idle
rpm 1600 ± 200
Valve Clearance (cold)
mm (in.) 0.1 (0.004)
Air Cleaner
type Replaceable dry type, paper element with foam precleaner
Engine Lubrication
oil grade Above 4° C (40° F) use
SAE30; Between -9° C
(15°F) and 4° C (40° F)
SAE20; Below -9° C (15°F)
SAE 10W30
Between -20° C (-4°F) and
30° C (86° F) use either
10W30 or 10W40.
Above 30° C (86°F) to 40°C
(104°F) use only 10W40
service class SC or better
Engine Oil Capacity
ml (oz.) 600 (20)
Fuel
type Regular leaded or unleaded gasoline
Fuel Tank Capacity
l (qts.) 2.8 (3.0) 3.6 (3.8)
Spark Plug
NGK B6HS NGK B6ES
Electrode Gap
(mm) in. 0.6–0.7 (0.02–0.03)
