Maintenance VPR 1330
wc_tx000107gb.fm 26
5.8 Cleaning Fuel Strainer
See Graphic: wc_gr000089
5.8.1 Turn fuel valve off.
5.8.2 Remove bowl (a) gasket (b) and screen (c).
5.8.3 Wash them thoroughly in a nonflammable solvent. Dry them and
reinstall.
5.8.4 Turn fuel valve on and check for leaks.
5.9 Throttle Adjustment
See Graphic: wc_gr000090
5.9.1 Place machine on a rubber test mat to prevent it from moving.
5.9.2 Start engine and allow it to warm up to operating temperature.
5.9.3 Move throttle control to high speed position (a).
5.9.4 Adjust throttle stop screw (b) to set operating speed.
CAUTION: Running plate at a speed higher than that listed in
Technical Data can damage both the plate and the engine.
