Page #46 background imageLoading...
Page #46 background image
46
46
Index
Contents
Index
Contents
TESTING YOUR TOOLS
If your tool does not work as you expect, it is a good idea to first check the assigned functions or to reset the
tool to its default condition using the Pen Tablet control panel.
1. Check the pen.
Move your pen across the active area of the tablet; the screen cursor should move in the
corresponding direction on your display screen.
Press the pen tip against the surface of the tablet. The power indicator light should turn from blue to
green.
Next, without applying pressure to the pen tip, hold the pen tip within approximately 5 mm (0.20 inch)
above the tablet surface and press the side switch. The power indicator light should again change
from blue to green.
Turn the pen over and press the eraser against the surface of the tablet; the power indicator light
should change from blue to green.
If not, you may have a defective pen or tablet. See t
echnical support options.
2. Check the cordless mouse.
Move the cordless mouse across the active area of the tablet; the screen cursor should move in the
corresponding direction on your display.
Test the buttons on your cordless mouse by clicking each button. The tablet power indicator light
should turn green when a button is pressed.
If not, you may have a defective cordless mouse or tablet. See t
echnical support options.
