MBC-8IU, MBC-16IU Technical data
43
11 Technical data
Versions, technical modifications and delivery options reserved.
Item number MBC-8IU MBC-16IU
Input voltage range: 207 V
AC
to 253 V
AC
207 V
AC
to 253 V
AC
Input current: 1.5 A 2.5 A
Power consumption when not
charging: 2 W 5 W
Efficiency factor during rated
charging: 52 % 52 %
Maximum efficiency level: 75 % 75 %
Nominal battery voltage: 12 V
DC
12 V
DC
Battery voltage range: 2.5 V
DC
to 15.6 V
DC
. 2.5 V
DC
to 15.6 V
DC
.
Absorption voltage: 14.4 V
DC
14.4 V
DC
Retention voltage: 13.6 V
DC
13.6 V
DC
Rated charging current: 2/4/6/8 A 2/4/8/16 A
Maximum output voltage
during reconditioning: 15 V
DC
15 V
DC
Output current during
reconditioning: 2 A stage: 0.25 A
4 A stage: 0.5 A
6 A stage: 0.75 A
8 A stage: 1 A
2 A stage: 0.25 A
4 A stage: 0.5 A
8 A stage: 1 A
16 A stage: 2 A
Charging characteristics: IU Automatik IU Automatik
Maximum ambient
temperature: 0°C to +40°C 0°C to +40°C
Dimensions (W x H x D): 270 x 195 x 155 mm 270 x 195 x 155 mm
Weight: 1.75 kg 1.96 kg
