PerfectPower Fastening and connecting the inverter
33
Fasten the inverter as follows (fig. 5, page 4):
a
Caution
Before drilling any holes, make sure that no electrical cables or
other parts of the vehicle can be damaged by drilling, sawing and
filing.
➤ Clip two holders on the left bar and two on the lower right bar.
You can move the holders as required.
➤ Fasten the inverter by screwing one screw through each hole in the
holder.
8.2 Connecting the inverter
a
Caution
The inverter may only be connected by a qualified workshop.
The following information is intended for specialists who are
familiar with the guidelines and safety precautions to be applied.
Observe the following safety instructions for the electrical connections:
e
z Caution – Risk of short circuit!
When working on the vehicle, always disconnect the earth
connection to the supply battery.
z Disconnect the 230 V external power supply to the caravan.
z If you have to feed cables through metal walls or other walls with
sharp edges, use ducts or tubes to prevent damage.
z Do not lay cables which are loose or bent next to electrically
conductive material (metal).
z Fasten the cables securely.
z Do not pull on the cables.
z Do not lay the 230 V mains cable and the 12/24 V DC cable in
the same duct.
z Lay the cables so that they cannot be tripped over or damaged.
_PP1000_PP2000.book Seite 33 Dienstag, 6. April 2010 4:31 16
