Power Dome
™
NX by Wagan Tech
®
9
www.wagan.com
6. The radio can hold up to 20 AM and 20 FM station presets in memory.
3.5MM AUDIO INPUT
1. Turn the radio on.
2. Insert a 3.5mm audio cable into the audio input jack.
3. The opposite end of the cable should be plugged into a compatible audio
device.
4. Turn on the audio device and set it to output sound. The sound should be
audible from the Power Dome speakers.
5. The Power Dome’s USB Power Port can conveniently power your audio
device.
USING THE AIR COMPRESSOR
The Air Compressor can inflate a variety of tires and inflatable equipment. It can
provide inflation pressure up to 260 PSI (pounds per square inch). Be careful not to
over-inflate by monitoring the compressor gauge while inflating. The Compressor’s
ON/OFF switch is located above the compressor hose and nozzle compartment.
CAUTION: Never connect or disconnect the nozzle with the compressor operating.
1. Before inflating any tire, look for the recommended inflation pressure
information on the inside of the car door.
2. Open the compartment door on the side of the Power Dome and extend
the hose.
3. Position the Power Dome so that you can see the Pressure Gauge.
4. Make sure the chuck lever is positioned UP (away from the chuck opening).
5. Remove the valve cap from the valve stem.
6. Attach the chuck to the tire’s valve stem and move the chuck lever DOWN
to secure the chuck to the valve stem.
7. Turn compressor switch to the ON position.
8. Monitor the pressure gauge while inflating the tire.
9. When the recommended tire pressure has been reached, turn the
compressor OFF.
10. Disconnect the hose and replace the valve cap.
11. Store the hose in the Air Hose compartment.
12. Recharge the Power Dome as soon as convenient.
