Controls and Functions
Air hose
Spray Gun
Turbine
Spray gun
handle
Air pressure
control selector
Material ow control
Filter housing
Turbine
handle
Spray gun holder
Trigger
Material contaner
Adjustment
ring
Spray width
lever
Air pressure control
selector:
The air pressure control selector
adjusts the level of air pressure
produced by the turbine.
1 = Thin materials
2 = Thick materials
Spray Width Lever:
The spray width lever
determines the width of the
spray pattern.
Material Flow Control:
The material ow control
determines the amount of
spray material that is sprayed
from the spray gun.
