Assembly
Before you begin:
NEVER point the spray gun at
any part of the body.
To Assemble:
IMPORTANT: Make sure the power cord is
unplugged.
1. Insert the suction tube into the intake opening.
2. Align the suction tube -
a. If you are going to be spraying in a downward
direction, the angled end of the suction tube
should be pointing toward the front of the gun.
b. If you are going to be spraying in an upward
direction, the angled end of the suction tube
should be pointing toward the rear of the gun.
Note: Make sure the suction tube is inserted as far as
it will go to ensure a tight t.
3. Carefully screw the cup back onto the nozzle
assembly. Tighten rmly.
2b
3
2a
1
To Next Page
