WAGNER 0558021 Original Operating Manual

ProSpray3.29•3.31 29
Item Part No. Description
1 0290 263 Retainer
2 0290 255 Jam nut
3 0290 276 Spacer
4 ------- Upperpacking
5 0290 249 Upperhousing
6 0508 343 Fitting
7 ------- Lower packing
8 0508 712 Guide ring
9 0507 730 O-ring (2)
10 0507 731 O-ring (2)
11 0290 250 Lower housing
12 0290 251 Piston rod
13 0507 734 Upperseal
14 0507 452 Upperballguide
15 9841 502 Outlet valve ball
16 0507 454 Washer
17 0294 516 Outlet valve seat
18 0507 733 Outlet valve retainer
19 0507 729 Lower ball guide
20 51519 Inlet valve ball
21 00310 Inlet valve seat
22 0509 582 O-ring
23 0508 717 Inlet valve housing
24 0290 237 Piston assembly (includes items 12-18)
0508 221 Repacking kit - 1 (includes items 3-4, 7-10,
13, 15, 16, 20 and 22)
0558 729 Repacking kit - 1 (includes items 3-4 and
7)
0552 150 Lower packing insertion tool
