ProSpray3.29•3.31 7
GB
Description of unit
7
8
2
1
3
5
6
4
9
10
13
12
11
14
 
1 Spray gun
2 High-pressure hose
3 Oil cup for EasyGlide (EasyGlide prevents
increased wear of the packings)
4 Oil level gauge
5 Pail hook
6 Oil button
7 Suction tube
8 Return hose
9 Cart
10 Relief valve
Lever position vertical – PRIME ( k circulation)
Leverpositionhorizontal–SPRAY(p)
11 Digital Electronic Spray Control (DESC)
12 Control panel indicators
13 Pressure control knob
14 ON/OFF switch
 
