19
AG 19
Technical Data
Max. operating pressure 25 MPa (250 bar) 53 MPa (530 bar)
Material inlet thread size 3/8” NPS 1/4” NPS
Diuser thread size 7/8” NPS (G thread)
11/16” NPS (F thread)
Wetted parts material High-grade steel, aluminum, PTFE, hard metal
Operating temperature range 5ºC to 40ºC
Maximum material
temperature
43ºC
Weight (cpl. incl. tip guard and
tip)
680 g
Introduction
This airless spray gun is to be used for the high pressure atomization of liquid
coating materials.
The 250 bar version is especially suitable for processing spray ller.
The 530 bar version is best suited for protective coating applications and can
be used with all pumps that can generate such a high pressure.
Using the Gun Trigger Lock
Always engage the gun’s trigger lock when the gun is not in use.
1. To lock the trigger, turn the trigger safety lock up as far as it will go.
2. To unlock the trigger, turn the safety lock downwards.
Gun locked
(gun will not
spray)
Gun unlocked
(gun will
spray)
