Operation
1. Make sure the arrow on the tip handle is pointing in the forward
direction for spraying.
2. Start the sprayer. Refer to the instructions in the sprayer’s Owner’s
Manual.
3. Adjust the uid pressure on the sprayer until the spray is completely
atomized. Always spray at the lowest pressure necessary to get the
desired results.
The spray tip determines the size of spray pattern and
coverage. When more coverage is needed, use a larger tip
instead of increasing uid pressure.
4. To clear a clogged tip:
a. Rotate the tip 180º so that the arrow on the tip handle is pointing
opposite the spray direction.
b. Trigger the gun once so that the pressure can blow the clog out.
Never pull the trigger more than once at time with the tip in
the reverse position.
c. Continue this procedure until the tip is clear of the clog.
Changing a Tip
Tips can be removed and replaced easily without disassembling the gun.
Identifying Tip Sizes
To identify tip sizes, use the following formula. A “517” tip size will be used in
this example.
The rst digit multiplied by two represents the size of the spray pattern when
spraying 12” away from the work surface:
5 x 2 = 10” spray pattern
The second two digits represent the diameter of the orice on the tip:
17 = .017” orice
Never attempt to change or clean the tip or tip guard without
rst performing the “Pressure Relief Procedure.”
1. Perform the “Pressure Relief Procedure” described in the sprayer’s
Owner’s Manual.
2. Remove the tip from the slot on the tip guard.
To Next Page
