WAGNER AG-19 User Manual

133
AG 19
Item Part # Description
1 0335301
2339659
Cap (250 bar)
Cap (530 bar)
2 2343936 Label (right)
3 2332588 Handle recess
4 2343935 Label (left)
5 2344878
0347335
Pressure spring (250 bar)
Pressure spring (530 bar)
6 2347489
2348175
Service Kit (F thread)
Service Kit (G thread)
7 2332598 Cylinder pin
8 9910403 Cap nut
9 2343066
2343158
Gun housing 250 bar
Gun housing 530 bar
10 2343085 Bolt
11 0553xxx
0559xxx
Tip (250 bar)
Tip (530 bar)
12
0289391
0289390
0289396
0289395
Tip guard
250 bar, F thread
250 bar, G thread
530 bar, F thread
530 bar, G thread
13 2332605 Guard rail
14 2333189 Trigger, cpl.
15 0043303 Grip seal
16 0034377
0097024
0089323
0097025
Gun lter (white, 1 pc.)
Gun lter (white, 10 pc.)
Gun lter (green, 1 pc.)
Gun lter (green, 10 pc.)
17 2347490
2347492
Threaded connection,
cpl (250 bar)
Threaded connection,
cpl (530 bar)
GB
Spare parts list
F
Liste de pièces de rechange
N° Référence Désignation
1 0335301
2339659
Vis d’obturation (250 bar)
Vis d’obturation (530 bar)
2 2343936 Plaque ( à droite)
3 2332588 Poignée
4 2343935 Plaque (à gauche)
5 2344878
0347335
Ressort de compression
(250 bar)
Ressort de compression
(530 bar)
6 2347489
2348175
Kit de maintenance (let F)
Kit de maintenance (let G)
7 2332598 Goupille cylindrique
8 9910403 Écrou borgne
9 2343066
2343158
Corps du pistolet 250 bar
Corps du pistolet 530 bar
10 2343085 Goujon
11 0553xxx
0559xxx
Buse (250 bar)
Buse (530 bar)
12
0289391
0289390
0289396
0289395
Support de buse
250 bar, let F
250 bar, let G
530 bar, let F
530 bar, let G
13 2332605 Arceau de protection
14 2333189 Gâchette cpl.
15 0043303 Joint de poignée
16 0034377
0097024
0089323
0097025
Filtre (blanc, 1 unité)
Filtre (blanc, 10 unités)
Filtre (vert, 1 unité)
Filtre (vert, 10 unités)
17 2347490
2347492
Pièce vissée cpl. (250 bar)
Pièce vissée cpl. (530 bar)
