English
4
1. Align the arrow on the spray gun with the “unlock”
symbol on the turbine.
2. Insert and twist the spray gun into the turbine toward the
“lock” symbol on the turbine. The tab below the trigger
will lock the two pieces into place.
1. Stir the spraying material thoroughly before measuring
viscosity.
2. Dip the viscosity test cup completely into the spraying
material.
3. Hold the test cup up and measure the time in seconds
until the liquid empties out. This time is referred to
below as Runout Time.
Thinning Chart
Material Runout Time
1) Oil enamel
2) Oil based primer
3) Oil stain
4) Clear sealer
5) Polyurethane
6) Varnish
25-40
30-45
No thinning required
No thinning required
No thinning required
20-50
1. Unscrew the cup from the spray gun.
2. After the material has been properly thinned and
strained, ll the container to the top of the neck.
3. Carefully screw the cup back onto the spray gun.
