WAGNER FLEXIO 3500 User Manual

EN
5
CONTROLS AND FUNCTIONS
3500
2500
XBOOST™ POWER DIAL / SWITCH
The X-Boost power dial / switch adjusts the level of air power produced by the
turbine.
The FLEXiO sprayer model 3500 is equipped with a variable speed air power control
(1 - 12).
The FLEXiO sprayer model 2500 is equipped with a 2-speed air power control (HI / LO).
ON / OFF SWITCH
The ON/ OFF switch turns the turbine ON (I) and OFF (0).
No spray material will be delivered until trigger is pulled.
iSPRAY
DETAIL FINISH
MATERIAL FLOW CONTROL
The material ow control determines the amount of spray material that is sprayed
from the spray nozzle.
iSpray Nozzle - The material ow can be adjusted incrementally from 1 (minimum) to
12 (maximum) by turning the adjustable material ow control.
Detail Finish Nozzle (3500 only) - Set the material ow by turning the red knob on
the trigger of the spray gun.
TRIGGER
Pulling the trigger will deliver material from the material container to the nozzle
assembly, where it is sprayed.
WIDE
NARROW
SPRAY WIDTH LEVER iSPRAY ONLY
The spray width lever determines the width of the spray pattern.
iSPRAY DETAIL
FINISH
=
=
=
ADJUSTMENT RING
The spray pattern shape is adjusted by turning the adjustment ring to either the
vertical or horizontal positions.
=
=
=
=
=
Horizontal pattern (use ‘up and down’ spraying motion)
=
=
=
=
=
Vertical pattern (use ‘side to side’ spraying motion)

WAGNER FLEXIO 3500 Specifications

General

Power Source	Electric
Flow Rate	Up to 8.0 gallons per hour
Nozzle Included	Yes
Spray Patterns	Horizontal, Vertical
Nozzle Type	iSpray Nozzle
Usage	Indoor/Outdoor
Spray System	Airless
Container Capacity	1.5 qt
Warranty	1 year limited
Flow Control	Adjustable
Weight	6.6 lbs
