PXM
OPERATING AND ASSEMBLY MANUAL
VERSION 08/2015 ORDER NUMBER DOC2350372
Pos K Quantity Order No. Designation
2 4 2359887 Spacer bushing injector plate
3 2 2359888 Square holder for injectors
4 20 2359892 Suction tube
5 20 2359893 Injector connection
6 20 -- Injector
7
2 2354873 Guide piece suction
8 1 2359897 Adjustment plate
10
2 2359900 Clamp uid tube
12 8 2354876 Poroplast tube for uidization
13 8 2359943 Screw plug
14 1 2359944 Clamp for level sensor
15 1 2359949 Tube for level sensor
16 1 2359954 Plug connection 1/4"
17 1 2359957 Adapter connection probe tube
18 4 2359899 Hand knob M8x30
21 1 2359959 Angled pipe connection 1/4" level sensor
22 2 2354875 Fluidization connection
23
16 2360988 O-ring
24 2 2361284 Box uidization
Wearing part
