78
PXM
P_02535
OPERATING AND ASSEMBLY MANUAL
VERSION 08/2015 ORDER NUMBER DOC2350372
9. The end of injector cleaning is displayed by a white "Blow out injector On" button
and a yellow "Blow out injector O " button.
10. Clean the ultrasonic sieve if necessary.
11. Clean the IP 5000 fresh powder pump.
There is the possibility of normal cleaning here (during tone-in-tone paint changes)
or intensive cleaning.
Note: When connecting the PXM to a nal lter, no powder may be whirled/blown
o in the booth during this time.
12. "Standard" cleaning sequence: Put suction lance in the park position (depicted left)
and snap into the clamp.
13. Plug the feed hose in the park position (pictured right).
14. Press "FP pump Standard On" button; the pump's own cleaning program is running.
Home page
Cleaning
Settings
Alarm
Worker
Injector
On
On
On
O
O
O
End
On O
FP pump standard
On O
FP pump intensive
US Sieve
RP hose
