Components and Description
The shipping carton for your painting system contains the following:
 • Spraygunwithtwolters(MingunandoneXS-SandoneMseparate) •Oneaxle,twoaxleplatesandfourscrews
 • Twowheelassemblies(including2metalcoversand2plasticcovers)  •Spraytipassembly
 • 7.5m,1/4”internaldiameterpressurehose    •Oneinletvalvepushertool
 • Anassemblyaid(positionedbeneaththehopper)    •Instructionmanual
Figure 1 - Controls and Functions
(further, detailed descriptions of the individual items can be found in the relevant section of the operating
instructions)
Item Component Description
A) Extendable handle .......................Thehandleextendsforeasytransportandstorage.
B) Removable Hopper ......................Thehoppercanberemovedforeasyemptyingandcleaning.Itcanberemovedwhenemptyor
when lled with material. Do not exceed 9.5 liters. The cover of the hopper does not seal, therefore
material can emerge from the upper container if too much material is put in or the hopper tips up.
 C) ON/OFFSwitch ............................TheON/OFFswitchturnsthepowertothesprayeronando(O=OFF,l=ON).
 D) PRIME/SPRAYKnob ....................ThePRIME/SPRAYknobdirectsuidtothesprayhosewhensettoSPRAYorthereturntubewhenset
to PRIME. The arrows on the PRIME/SPRAY knob shows the rotation directions for PRIME and SPRAY.
ThePRIME/SPRAYknobisalsousedtorelievepressurebuiltupinthesprayhose(seePressureRelief
Procedure).
E) Project Control ...............................ProjectControlfunctions:Prime,Clean/Roll,Spray1-MAXSpray.
F) Return Tube ....................................Fluid is sent back out through the return tube to the original container when PRIME/SPRAY knob is in
PRIME position.
G) Handle lock .....................................The handle lock allows the extendable handle to extend or contract.
 H) SprayGun ........................................Forapplicationofthecoatingmaterialandregulationofthepumpcapacity.
 I) SprayHose ......................................Thesprayhoseconnectstheguntothepump.
When working outdoors:
Danger
Vapors containing solvents may not be allowed to
blow toward the unit.
Note the direction of the wind.
Set the unit up in such a way that vapors containing
solvents do not reach the unit and build up there.
A minimum distance of 5 m between the unit and
spray gun is to be maintained.
U Cleaning the unit
Danger
Danger of short circuit through penetrating water!
Never spray down the unit with high-pressure or
high-pressure steam cleaners.
U Cleaning units with solvents
Danger
When cleaning the unit with solvents, the solvent
should never be sprayed or pumped back into a
container with a small opening (bunghole). An
explosive gas/air mixture can be produced. The
container must be earthed.
Do not clean the device or accessories with
ammable solvents with a ash point below 21 °C.
U Earthing of the object
The object to be coated must be earthed.
Technical Data
Pumptype Piston pump
Power source 230-240 V
~
50 Hz
Power consumption 625 W
Fusing
Onlyconnecttosocketsprotected
with an FI fuse (16 A)
Double insulation
Max.spraypressure 190 bar
Max.deliveryrate
1)
0,8 l/min
Sound pressure level
2)
L
WAd
=(80+3)dB(A)
Sound pressure output
2)
L
pAd
=(91+3)db(A)
Oscillationlevel
2)
a
h
=1,2m/s
UncertaintyK=1.5m/s²
Max. temperature of coating
substance 48°C
Max. nozzle size L (0,017")
Technical Data
Hose length 7,5 m
Containercapacity 9,5 l
Product dimensions 38 x 38 x 65 cm
Weight 12 kg
1)
Dispersion paint with nozzle M and a pressure of 138 bar
2
)
Measured in accordance with EN 1953 in an acoustic measuring
roomwithpaintsprayedatmaximumpressure
Coating Materials Suitable for Use
Water-based and solvent-containing lacquers and glazes.
Paints,oils,releaseagents,syntheticenamels,PVClacquers,
undercoats, base coats, llers and anti-rust paints.
Dispersion and latex paints for interior use.
