Wagner Project 115 - 0418A
i
Under pressure, the spray tip may be very dicult to
turn. Turn the PRIME/SPRAY knob to PRIME and
trigger the gun. This will relieve pressure and the tip
will turn more easily.
 2. Turntheprime/sprayknobtospray.
3. Unlock the gun and squeeze the trigger, pointing the gun at
a scrap piece of wood or cardboard. This allows pressure in
thesprayhosetoblowouttheobstruction.Whenthenozzle
is clean, material will come out in a straight, high pressure
stream.
4. Release the trigger and lock the gun o. Reverse the tip so
the arrow points forward again. Unlock the gun and resume
spraying.
Cleanup
i
If you are using water-soluble materials, use warm suds
to clean the spray device. If you are using solvent-
based spray, use a suitable solvent for cleaning, with a
ash point of over 21°C.
i
Do not use solvents for water-soluble materials, as the
mixture will turn into a gel-type substance which is
dicult to remove.
Figure 16 - Short Term Cleanup
i
Only follow these instructions when using water-
soluble materials. If you are using solvent-based spray,
follow the Cleanup and Long-Term Storage steps.
A) Shutdown
1. Perform the Pressure Relief Procedure (see gure 7) and
unplug the sprayer.
 2. Pour1/2cupwaterslowlyonthetopofthepainttoprevent
thepaintfromdrying.
 3. Wrapthespraygunassemblyinadampclothandplaceitin
aplasticbag.Sealthebagshut.Placethesprayerinasafe
place out of the sun for short-term storage.
B) Startup
1. Remove the gun from the plastic bag. Stir the water into the
paint.
2. Turn the PRIME/SPRAY knob to PRIME.
 3. Plugsprayerin.
 4. TurntheswitchtoON(I).
 5. TurnthePRIME/SPRAYknobtoMAXSPRAY.Testthesprayer
onapracticepieceandbeginspraying.
Figure17-FlushingtheSystem
1. Perform Pressure Relief Procedure (see gure 7).
 2. Emptythehopperofsprayingmaterial(seegure8).
3. While removed, rinse the hopper with the appropriate
cleaning solution until clean.
 4. Lockthegunandremovespraytipassembly.Replacethe
hopper and return tube. Fill the hopper with appropriate
cleaning solution.
5. Place a waste container (a) next to the original material
container (b). The containers should be touching. Aim the
spraygunintothesideoftheoriginalmaterialcontainer(b)
and hold the trigger.
 6. Whilepullingtheguntrigger,turnthepumpON(l),and
turn the PRIME/ SPRAY knob to SPRAY (1) to purge material
fromthehosebackintotheoriginalcontainer.Keepholding
trigger through next steps.
 7. Whencleaningsolutionowsfromthespraygun,keep
holdingthetriggerandaimthespraygunintothesideofthe
waste container (ground gun with a metal container if ushing
with ammable solvent).
8. Trigger the gun until the uid owing out of the gun is clear.
Youmayneedtodisposeandobtainnewcleaningsolution.
9. Turn the PRIME/SPRAY knob to PRIME and trigger gun to
relieve pressure.
 10. Ifhopperisemptyofallcleaningsolution,rellwithnew
cleaning solution.
 11. TurnthePRIME/SPRAYknobtoPRIME,andturnthepumpON.
12. Let the pump circulate the cleaning solution out the return
tubefor2-3minutes.TurnthepumpOFF.
 13. Removeandthoroughlyrinsethehopperoncemore.
14. Replace the hopper for storage.
Figure18-CleaningtheSprayGun
1. Perform Pressure Relief Procedure (see gure 7).
 2. MakesurethepumpisswitchedOFF(O).Makesurethe
PRIME/SPRAYknobisturnedtoPRIME.Unplugthesprayer.
 3. Removespraygunfromthepainthoseusingadjustable
wrenches.
 4. Unclipthetriggerguard(a)fromthelterhousing(b)by
pulling outward from the lter housing. Unscrew the lter
housing.
 5. Removethelter(c)fromthespraygunhousingandclean
with the appropriate cleaning solution (warm suds for water-
soluble materials, solvents with a ash point of over 21°C for
solvent-based substances).
 6. Removespraytip(d)fromsprayguardassembly.Cleanspray
tip with a soft-bristled brush and the appropriate cleaning
solution. Be sure to remove and clean the washer (e) and
saddleseat(f)locatedintherearofthespraytipassembly.
7. Replace the cleaned lter, tapered end rst, into the gun
housing. The tapered end (g) of the lter must be loaded
properlyintothegun.Improperassemblywillresultina
plugged tip or no ow from the gun.
 8. Installspraytip(d),saddleseat(f)andwasher(e),andreplace
sprayguardassembly.
 9. Threadthespraygunbackontothepainthose.Tightenwith
a wrench.
Figure 19 - Long-Term Storage
1. Perform Pressure Relief Procedure (see gure 7).
 2. Removehopper.Pourapproximatelytwoouncesoflight
household oil into the inlet valve (a).
 3. Removehosefromsprayhoseport.Placearagoverthespray
hoseport,andturntheswitchON(l).Lettheunitrunfor
veseconds.TurnthepumpOFF(O).Disconnect the spray
device from the power supply.
4. Replace the hopper.
5. Wipe entire unit, hose and gun with a damp cloth to remove
accumulatedpaint.Replacethesprayhose.
6. Push handle lock to collapse the handle.
