5) Insert the suction tube with container seal in the gun body.
In order to mount the gun more easily apply lubricating grease (enclosed) liberally
to the O-ring at the gun front part (Fig. 18, 4).
17. Maintenance
Air lter
WARNING! Never operate the machine without the air lter; dirt could be sucked
in and interfere with the function of the machine.
Disconnect plug before changing parts.
•
Change the air lter if it is soiled.
•
For this pull the air lter out of the unit (Fig. 17).
•
Insert a new air lter into the compartment.
Ventilating hose / Valve
1) Pull the ventilating hose (Fig. 12, 1) at the top from the gun body. Screw o the valve
cover (2). Remove the diaphragm (3). Carefully clean all parts or replace in the
event of damage.
2) Place the diaphragm (Fig. 12, 3) with the pin facing upwards on the bottom section
of the valve. Also see the marking on the gun body.
3) Place on the valve cover (Fig. 12, 2) and screw it closed.
4) Place the ventilating hose (Fig. 12, 1) on the valve cover and on the nipple at the gun
body.
18. Spare Parts
Spare Parts List (Fig. 18)
Pos. Name Order No.
1 Wall Extra I-Spray spray attachment incl. 1300 ml container 2361 746
2 Air cap 2382 753
3 Union nut and nozzle 2382 751
4 O-ring 2362 875
5 Ventilating hose, valve cover, diaphragm 2382 754
6 Suction tube 2389 021
7 Container seal 2389 023
8 Container with cover 1300 ml (only for Wall Extra I-spray
spray attachment)
2305 155
9 Handle 0414 911
10 Air hose 2308 501
11 Carrying belt 2322 299
12 Air lter 2308 502
13 Feed hopper (3 pcs.) 2304 028
