16 Device Description EPSITRON®
787-1668 Electronic Circuit Breaker
Manual
Version 1.1.0
Total current exceeds 40 A!
Distribute the current to input terminals "IN1" and "IN2" when the total current
should exceed 40°A, as otherwise the plug-in connectors will become overheated
and can be damaged or destroyed.
Pos: 24.7 /S erie 78 7 (E PSI TRON )/ Ger äteb esc hrei bung / Ansc hlüs se/ Ans chl üss e 78 7-1668 - Abges ich erte Ausg änge @ 12\mod_1342099465661_21.docx @ 100030 @ 3 @ 1
3.2.2 Fuse-Protected Outputs
Table 8: Connections – Fuse-protected outputs
Figure 4: Fuse-protected
outputs Ch1 … Ch8
No.
Designation
Function
1 … 8
Ch1 … Ch8
Fuse-protected outputs
Ch1 … Ch8
Pos: 24.8 /S erie 78 7 (E PSI TRON )/ Ger äteb esc hrei bung / Ansc hlüs se/ Ans chl üss e 78 7-166x - Steu er- und Signalkontakte @ 13\mod_1345544033477_21.doc x @ 101808 @ 3 @ 1
3.2.3 Control and Signaling Contacts
Table 9: Connections – Control and signaling contacts
Figure 5: Control and
signaling contacts
No.
Designation
Function
1
S1
Control Input S1
2
S2
Signal Output S2
3
S3
Signal Output S3
Pos: 25 /Doku ment ation all gemei n/Gli eder ungsel eme nte/---Seit en wechs el--- @ 3\mod_1221108045078_0.docx @ 21810 @ @ 1
