WAGO EPSITRON 787-1668 Series User Manual

8 Notes about this Documentation EPSITRON®
787-1668 Electronic Circuit Breaker
Manual
Version 1.1.0
Pos: 12 .6 /All e Seri en (Allg emeine Modul e)/Hi nweis e zur Do kument ation /Zahl ensy steme @ 3\ mod_1221059454015_21.docx @ 21711 @ 2 @ 1
1.4 Number Notation
Table 2: Number notation
Number code
Example
Note
Decimal
100
Normal notation
Hexadecimal
0x64
C notation
Binary
'100'
'0110.0100'
In quotation marks, nibble separated with
dots (.)
Pos: 12 .7 /All e Seri en (Allg emeine Modul e)/Hi nweis e zur Do kument ation /Schr iftko nventi one n @ 3\mod_1221059521437_21.docx @ 21714 @ 2 @ 1
1.5 Font Conventions
Table 3: Font conventions
Font type
Indicates
italic
Names of paths and data files are marked in italic-type.
e.g.: C:\Programme\WAGO-I/O-CHECK
Menu
Menu items are marked in bold letters.
e.g.: Save
>
A greater-than sign between two names means the selection of a
menu item from a menu.
e.g.: File > New
Input
Designation of input or optional fields are marked in bold letters,
e.g.: Start of measurement range
“Value”
Input or selective values are marked in inverted commas.
e.g.: Enter the value “4 mA” under Start of measurement range.
[Button]
Pushbuttons in dialog boxes are marked with bold letters in square
brackets.
e.g.: [Input]
[Key]
Keys are marked with bold letters in square brackets.
e.g.: [F5]
