smartPRINTER Operating Instructions
smartPRINTER Operating Instructions 003/10.2017 12
Ink ribbon rewinder
Ink ribbon unwinder
Rotating wheel, green,
Ø 40 mm
Ø 40 mm
Cardboard core
holder
Ink ribbon
spool holder
Rotating wheel, white, Ø
30 mm
Ø 30 mm
Print head
Printing mechanism
