50
EN
PRODUCT OVERVIEW AND
BUTTON FUNCTIONS
1 Wind Vane 7 Solar panel
2 Wind Speed Sensor 8 U-Bolt
3 UV sensor/ Light sensor 9 Battery compartment
4 Thermo-hygro sensor 10 Reset button
5 Rain collector 11 LED Indicator: light on for
4s if the unit power up. Then
the LED will ash once every
16 seconds (the sensor
transmission update period).
6 Bubble level
