54
EN
Mount outdoor sensor
Mounting outdoor sensor to your mounting pole (purchased separately) with
the U-bolts as shown in Figure 8.
Figure 8 Figure 9
Use the bubble level beside the rain sensor as a guide to verify that sensors are
level.
Reset Button and Transmitter LED
In the event the sensor array is not transmitting, reset the sensor array.
• With an open ended paperclip, press and hold the RESET BUTTON for
three seconds to completely discharge the voltage.
• Take out the batteries and wait one minute, while covering the solar panel
to drain the voltage.
• Put batteries back in and resynchronize with console by powering down
and up the console with the sensor array about 10 feet away.
