58
EN
Figure 13
Ref. LED Description
1 RF On when radio frequency receiver is operating
properly
2 Indoor On when indoor sensor received
3 Outdoor On when outdoor sensor array received
4 WIFI On when connect to WIFI router via APPs. On
when connected to internet hosting service
5 Power AC Power connected
