2. Model overview
For optimum installation and use of the luminaire, you have to identify the luminaire model.
To do so, you will require the model number of the luminaire.
NOTE: The model number can be found on the rating plate of the luminaire.
X Check which model number the luminaire has.
X Determine the luminaire model by referring to the following table, see Tab. 1. For an
explanation of the functions, see chapter 6 “Functions of the luminaire”, page 22.
Example: The model number MLAL 12 SD stands for the following luminaire model:
MLAL 12 S D
MACH LED PLUS
machine light
Key:
12
Connection:
SELV version
Version D
Functions:
 Switchable
 Through-wiring
Type Key Connection Model Functions
MLAL
MACH LED PLUS
machine light
12
27
42
57
S
SELV version
-
Switchable
D
Switchable
Through-wir-
ing
Tab. 1: Model overview.
