Electrical Supply Requirements
Electrical Connection
RN8510 / RN8610GE / GEC Models Only
.
Electrical supply connection point is located at the rear of the appliance, approximately 80 mm from
the right hand side and 466 mm from the rear and 150 mm from the floor.
RN8810GE/GEC Models Only
.
Electrical supply connection point is located at the rear of the appliance, approximately 380 mm from
the right hand side, 466 mm from the rear and 150 mm from the floor.
When connecting a this electric appliance to the mains supply, ensure that the following is carried
out:-
• An isolating switch is fitted within 2 m of the appliance, but not on the appliance and in
such a position that the user does not have to reach across the cooking surface.
• Supply cord shall be oil-resistant, sheathed flexible cable and not lighter than ordinary
polychloroprene or other equivalent synthetic elastomer sheathed cord (as per AS / NZS
3191 part 2.10.11. or IEC 60245-IEC-57) e.g. HO5 RN-F Type.
• The branch supply line shall be individually overload protected to the correct current rating
and the supply chord shall be protected against any mechanical or thermal damage.
• A grommet is fitted around the wiring entry hole into the appliance.
• All wiring connections must be tight.
Refer to the appropriate wiring standards for the size of cable that is to be supplied to an appliance
for the current drawn on that line.
Specifications
WARNING:
T
HIS APPLIANCE MUST BE EARTHED. IF THE SUPPLY CORD IS DAMAGED, IT MUST BE REPLACED BY A SUITABLY
QUALIFIED PERSON IN ORDER TO AVOID A HAZARD.
MODEL
1-Phase Connection
1P+N+E
230-240V
RN8510GE
5.5 kW,
22.6 Amps @ 235 V
5.5 kW
L1 - 7.2 Amps
L2 - 7.7 Amps
L3 - 7.7 Amps
RN8510GEC
5.8 kW,
23.9 Amps @ 235 V
5.8 kW
L1 - 8.5 Amps
L2 - 7.7 Amps
L3 - 7.7 Amps
RN8610GE
6.5 kW,
26.6 Amps @ 235 V
6.5 kW
L1 - 8.2 Amps
L2 - 9.2 Amps
L3 - 9.2 Amps
RN8610GEC
6.8 kW,
27.9 Amps @ 235 V
6.8 kW
L1 - 9.5 Amps
L2 - 9.2 Amps
L3 - 9.2 Amps
RN8810GE
6.5 kW,
26.6 Amps @ 235 V
6.5 kW
L1 - 8.2 Amps
L2 - 9.2 Amps
L3 - 9.2 Amps
RN8810GEC
6.8 kW,
27.9 Amps @ 235 V
6.8 kW
L1 - 9.5 Amps
L2 - 9.2 Amps
L3 - 9.2 Amps
3-Phase Connection
3P+N+E
400-415V
