Walker Edison HANB5B - Page 13

Step 16
Step 17
Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.13
D
D
R2
D
D
L2
D
L2
Attach slides (L2,R2) into parts (6,7) with
screw (D) and philips head screwdriver.
07
06
08
05
09
6x
C
C
06
08
07
09
05
C
C
Ø15x10mm
12
D
Ø3,5x14mm
24
L2
330mm
6
R2
330mm
6
6x
Secure part (05) into parts (6,7) using cam
lock (C) with philips head screwdriver.
