Walker Edison HANB5B - Page 12

Step 14
Step 15
Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.12
B
B
A
A
A
A
A
A
A
A
05
08
07
06
F
F
07
06
08
09
F
06
08
A
Ø8x30
48
B
Ø6x31mm
12
6x
Insert wooden dowel (A) into parts (6,7,8) and insert cam
bolt (B) into parts (5) with philips head screwdriver.
Secure parts (6,7) into part (8) using screw (F) and
philips head screwdriver. Slide part (9) into grooves
according diagram.
6x
F
Ø4x40mm
12
