Walker Edison HANB5B - Page 11

Step 12
Step 13
Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.11
C
C C
C
C
C
01
C
01
03
02
10
03
Slide back panel (11) into side panel (2,3,12)
with the painted outside.
Secure part (1) into parts (2,3,10) using cam lock
(C) and philips head screwdriver .
C
Ø15x10mm
6
11
Name and address of
the supplier and date of
production.
11
