A Ø 8x30mm Wooden Dowel 61 pcs
B Ø 6x31mm Cam Bolt
22 pcs
C Ø15x10mm Cam Lock 22 pcs
D Ø3,5x14mm Screw 68 pcs
E Ø 22x17mm Adjustable Foot
1 pcs
F Ø4x40mm Screw 18 pcs
G Ø 7x50mm Screw 10 pcs
H 14x14mm Support
32 pcs
I Ø 19mm Sticker 12 pcs
J 21x47x4mm Hex key 1 pcs
K1 150mm Foot
4 pcs
K2 139mm Center Foot 1 pcs
L1 330mm Slide 6 pcs
L2 330mm Slide
6 pcs
M Ø 6x8mm Screw
12 pcs
N Ø 6x20mm Screw 12 pcs
O1 Ø3,5x14mm Screw 1 pcs
O2 Ø4,5x35mm Screw
1 pcs
O3 Ø 10mm Washer 2 pcs
O4 Ø 6mm Wall anchor 1 pcs
O5 200x20mm Strap
1 pcs
P Ø 10x13mm Plastic Bushing 1 pcs
R1 330mm Slide 6 pcs
R2 330mm Slide
6 pcs
Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.4
Hardware List
The hardware quantities listed above are required for proper assembly.
Some extra hardware may also have been included.
