Walker Edison HANB5B - Page 5

Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.5
Step 1
Step 2
Insert plastic bush (P) into central foot (K2). Insert
adjustable foot (E) into bush (P).
E
Ø 22x17mm
1
K2
139mm
1
P
Ø 10x13mm
1
A
A
A
A
A
A
A
A
B
B
A
A
B
B
A
A
B
B
B
B
B
B
10
02
01
03
P
A
Ø8x30
12
B
Ø6x31mm
10
Insert wooden dowel (A) into parts (2,3,10). Insert cam
bolt (B) into parts (1,2,3) with philips head screwdriver.
E
K2
K2
