Walker Edison HANB5B - Page 9

Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.9
Step 8
Step 9
C
Ø15x10mm
2
C
C
03
12
C
Ø15x10mm
2
C
C
02
Secure part (12) into part (3) using cam lock
(C) with philips head screwdriver .
Secure part (12) into part (2) using cam lock
(C)
with philips head screwdriver.
12
