Maintenance Instructions LUBRICATION
50
Ident Lubrication No.
No. Location Type Places
Ident Lubrication No.
No. Location Type Places
1 DeckCasterWheelForkPivot Grease 2
2 DeckCasterWheelBearing Grease 2
3 TeeGearbox,Deck Oil* 1
4 BladeDriveGearbox Oil* 2
5 UniversalJointShaftAssembly Grease** 1
6 PivotAssembly,Tilt-UpDeck Grease 4
7 DeckSupportArmSocket Grease 2
8 BodyHingePoint Oil 2
9 FSCActuatorRodPivotPins Oil 2
10 FSCLeverPivot Grease 1
11 FSCLeverFork Grease 1
(GreaseSlideArea)
12 (FSC)FrictionBodyPivot Grease 1
13 SteeringLeverPivot Grease 4
14 DeckSupportArmPivot Grease 2
15 Deck-to-PTOCoupling Grease 1
(GreaseSlideArea)
16 UniversalJointTubeAssembly Grease** 1
17 UniversalJointQuickConnect Grease 1
Spline(GreaseSlideArea)
18 ParkingBrakeLever Grease 1
19 GearAxle Oil*** 2
20 BeltTightenerPivot, Grease 1
JackshaftDrive
21 ClutchActuatorPushRod Grease 2
22 PTOClutchLeverPivot Grease 1
23 BeltTightenerPivot, Grease 1
PTOClutch
24 BrakeActuatorRodandBrake Oil 3
BandPivotPins(Clevis)
25 BrakeActuatorPivot Grease 1
26 CatcherHingePoint Oil 2
27 ChokeControlCableEnds Oil 2
28 ThrottleControlCableEnds Oil 2
29 EngineOil Oil*** 1
30 BeltTightenerPivot, Grease 1
BlowerDrive(GHSModelOnly)
31 BeltTightenerPivot, Grease 1
GroundDrive
32 PTOGearboxDipstick Oil*** 1
33 HydrostaticDrive Oil*** 2
34 ChokeControlPivot Oil 1
35 ThrottleControlPivot Oil 1
* Gearboxes are permanently lubricated and
sealed requiring no scheduled lubrication. Oil
level should be checked only when an oil leak
is noted. Refer to Mower Deck Gear box Lu-
brication in this section.
** Grease every eight (8) hours.
*** Refer to Gear Axle Lubrication, Engine Oil,
Tractor PTO Gearbox Lubrication, and Hy-
drostatic Transmission Fluid in this sec-
tion.
NOTE: DGHS42 Tilt-Up Deck is shown for reference.
For other Deck Lubrication Points, Refer to
Deck and Carrier Frame Illustrated Parts Man
ual.
