Walker MC (20 HP - Cylinder Head Cooling Fins; Grass Buildup in Mower Housing

Maintenance Instructions CLEANING
55
Cylinder Head Cooling Fins
It is essential for performance and longevity of the
air-cooled engine to keep the cylinder head cooling
ns clean and free of obstruction. After every 8
hours of operation, check the performance of the
cooling system by starting the engine, holding a
hand adjacent to the cylinder head, and feeling the
cooling airow. If there is little or no airow, clean
the cooling ns as described below.
DANGER
Make sure to keep hands clear of exhaust
pipe, mufer, and moving parts when
checking airow.
Every 100 hours, inspect and clean the cooling ns
(more often when operating in extremely dusty, dirty
conditions). Remove the two (2) cooling n access
panels in the engine shroud and clean the cooling
ns and external surfaces using compressed air.
Make sure to reinstall the access panels before op-
erating the engine.
NOTE: If dirt is packed into the cooling ns it may
be necessary to remove the engine shroud in order
to thoroughly clean the cooling ns.
Engine Cooling
Fin Access Panels
Kohler Engine
Shroud
Engine Air
Intake Screen
Engine Air Intake Screen and
Cooling Fin Access Panels
Check Airow
with Hand
Cooling System Airow
Grass Buildup in Mower Housing
DANGER
Before raising or removing the mower
deck for cleaning, stop the engine, re move
the ignition key, and disconnect the spark
plug wires.
1. Raise the deck lock lever handle on each side
of the carrier frame and pull out to release car-
rier frame for tilting action.
2. Using the carrier frame lift handle, raise deck to
the TILT-UP position and insert the deck hook
into the tilt-up latch on the tractor body.
Tilt-Up Hook
Deck
Tilt-Up Latch
Tilt-Up Latch
Deck Lock Lever
Tilt-Up Lift Handle
Deck Secured in TILT-UP Position
