Component Identification
9
Air Restriction Indicator
(Not Visible)
Air Intake Hose
(Primary to Secondary)
Air Cleaner
Base Plate
Fuel Pump
Engine Air Cleaner
(Secondary)
Muffler Grass
Shield
Throttle and
Choke Linkage
Muffler Heat
Shield
Oil Dipstick/Oil Fill
Rubber Bumper
(Catcher Support)
Muffler
20 Amp Fuse
(Starter Solenoid)
GHS Blower
RH Hydrostatic
Transmission
PTO
Clutch Lever
30 Amp
Circuit Breaker
RH Transmission
Lockout Lever
Turbine
Precleaner
PTO Gearbox
Dipstick
Jackshaft
Positive (+)
Battery Cable
Negative (-)
Battery Cable
Battery
Donaldson Air Cleaner
(Primary Air Cleaner)
Neutral Safety
Switch
LH Transmission
Lockout Lever
LH Hydrostatic
Transmission
Precleaner
Tube
Fuel Tank
Air Cleaner
Cover
Fuel Filter
Top View (Engine Compartment)
