Instrument Panel
Instrument Panel
This illustration shows the configuration of the
switches and indicators located on the instrument
panel.
Hourmeter Voltmeter
Oil Pressure
Warning Light
Over Temperature
Warning Light
Ignition
Switch
Light Switch
(Optional)
Warning
Horn
