GRASS HANDLING SYSTEM (GHS)
GHS Model Only
GHS Flow and Components
PTO and Blade
Gear Drive
PTO
Clutch
Rear Discharge
Mower Deck
Deck
Discharge Chute
Blower
Body Chute
Assembly
Powerfil
®
Delivery Spout
Grass Catcher
Catcher
Door Spring
Catcher
Door
Exhaust
Deflector
Exhaust Screen
(Removable)
Catcher Door
Safety Latch
Grass-Pak
®
Vane Switch
Delivery
Chute
“Full” Signal
Horn
Actuator
Rod
Powerfil
®
Drive Motor
Dump Handle
