Walker T25i Operator's Manual

Specications
4
MODEL
T25i
TRANSMISSION (continued)
Transmission Fluid
Factory Service
Mobil 1 Synthetic Motor Oil (15W-50)
Transmission Oil Capacity oz. (L) 19 (.56)
Transmission Cooling
Cooling Fan Mounted on Drive Pulley
Ground Travel Speed
Forward MPH (km/h)
Reverse MPH (km/h)
0-7 (0-11.3) Innitely Variable
0-5 (0-8) Innitely Variable
BLADE DRIVE
PTO Shaft
Quick Disconnect Splined Shaft with Two (2) High-Speed U-Joints
Blade Drive Clutch and Brake Manual Belt Tightener Clutch and Band Brake [Stops Blades within
Five (5) Seconds of Disengagement]
TIRE SIZE
Deck Caster 8 x 3.00-4 (Pneumatic 4-Ply, All Decks Except DS52, DS62, DS74)
11 x 4.00-5 (Pneumatic 4-Ply, DS52, DS62, DS74 Only)
Drive 18 x 9.50-8 (Pneumatic 4-Ply, Standard)
18 x 10.50-10 (Pneumatic 4-Ply, Optional Low-Prole)
Rear Caster 13 x 5.00-6 (Pneumatic 4-Ply, Standard Dual)
13 x 8.00-6 (Pneumatic 4-Ply, Optional Single)
TIRE PRESSURE PSI (KPA)
Deck Caster Wheel 20 (137)
Drive 15 (103)
Rear 20 (137)
DRIVE BELTS
Engine PTO Walker P/N 8230
Jackshaft Drive
Walker P/N 6250-1
Ground Drive, Micro-V Walker P/N 7248
Blower (GHS Model) Walker P/N 7234-2
SEAT Contour-Molded, with Nylon Backed Vinyl Cover and
Integral Foam Cushion
FRAME/BODY CONSTRUCTION
Frame
All Welded Unitized Steel Chassis
Body 14 Gauge Steel
Deck 11 Gauge Steel
GHS Catcher and Chutes Molded Cross-Linked Polyethylene (UV Stabilized)
GHS SYSTEM
Blower 10.5 in. Diameter, Three-Blade Paddle Wheel
Blower Brake
Band Brake [Works in Combination with PTO Clutch, Stops
Blower within Five (5) Seconds of PTO Disengagement]
