5.0 Technical details: electrical connection - conditions
Electrical connection-conditions
Model
wallbe Pro
3,7kW
wallbe Pro
4,6kW
wallbe Pro
7,4kW
wallbe Pro
11kW
wallbe Pro
22kW
Input terminal
X1
L1/N/PE
X1
L1/N/PE
X1
L1/N/PE
X1
L1/L2/L3/N/PE
X1
L1/L2/L3/N/PE
Supply line
NYM-J
3x2,5mm²
NYM-J
3x2,5mm²
NYM-J
3x6mm²
NYM-J
5x2,5mm²
NYM-J
5x6mm²
LS_switch/
preliminary fuse
1 pol. x C 16A
1 pol. x C 20A
1 pol. x C 32A
3 pol. x C 16A
3 pol. x C 32A
RCD in switch
board
RCD Typ A
A0,03A/25A
RCD Typ A
A0,03A/25A
RCD Typ A
A0,03A/40A
RCD Typ A
A0,03A/25A
RCD Typ A
A0,03A/40A
1. Be aware that you have to install an adequate LS-switch (see table) in the electrical
sub distribution!
2. Be aware that your wallbe Eco 2.0 is already equipped with a DC residual current
detection >6mA. Therefore a cost intensive RCD Type A (EV) or Type B in the switch
board is not necessary.
3. We strongly advise you to follow local norms and regulations.
If you have any further questions please contact us! Phone: +49-5252-989440
