Wallbe Pro 3,7kW - Technical Details: Electrical Connection - Supply Line

wallbe GmbH – Paderborner Str. 76 – 33189 Schlangen
Tel: +49 5252 989440 Mail: inquiry@wallbe.de
24
5.1 Technical details: electrical connection – supply line
Electrical connection: 3,7kW to 22kW
Supply line
(Input
terminal X1)
wallbe Pro
3,7kW
wallbe Pro
4,6kW
wallbe Pro
7,4kW
Supply line
(Input terminal
X1)
wallbe Pro
11kW
wallbe Pro
22kW
brown or
black
L1
L1
L1
brown
L1
L1
blue
N
N
N
black
L2
L2
green
/yellow
PE
PE
PE
grey
L3
L3
blue
N
N
green
/yellow
PE
PE
